Non-Contact Ultrasonic Sensor - 120V Power
APPLICATON
DEPTH-120V is ideal for below-ground detention and infiltration stormwater infrastructure systems when 120V power supply is available at the site. Surface system application is also possible. Data is automatically sent to the P4 cloud-compute platform.
The computer is located within an electrical enclosure at the site. A cellular antenna is mounted to the exterior surface of an electrical enclosure. The computer is plugged into a standard 110V outlet (10 A circuit) within the enclosure. A Pulsar dBi intelligent ultrasonic transducer (sensor) is hung in pendant mode (think plumb bob) within a access manhole riser by a sensor support bracket attached to the wall of the manhole riser using "TapCon" or similar fasteners. Direct bury cabling (within a 1-1/2" inner diameter conduit or not) can be used to run the sensor wire to the on-site electrical cabinet where it can be plugged into the P4 computer.
WHAT'S INCLUDED & OPTIONS
Included with Kit:
1.) Small form factor NEMA IP67 data acquisition computer with external cellular antenna (hockey puck).
2.) Pulsar dBi intelligent ultrasonic transducer (sensor).
3.) 110V wiring and plug (wall wort).
4.) Direct-bury sensor extension wire (length dependent upon application)
5.) Sensor mounting bracket
Options:
1.) Direct-bury sensor extension wire (length dependent upon application)
INSTALLATION CONSIDERATIONS
Site power may require a dedicated and metered circuit on site. Installation should consider this and all necessary permitting should be pursued. Provisions should be made for a sensor wire conduit run from the access manhole riser to the electrical enclosure.
P4 can provide installation services - CONTACT P4 for more information.
PRICING
P4-DEPTH 120V (starting at $3,375)
Pricing does not include installation or shipping - contact P4.
1-Yr P4 Cloud Compute Subscription - $225/yr/kit ($19/mth)
Multi-year cloud-compute subscriptions are available (contact P4)
Non-Contact Ultrasonic Sensor - Battery/Solar Power
APPLICATION
DEPTH-Battery/Solar is ideal for below-ground detention and infiltration stormwater infrastructure systems when power is NOT available at the site. Surface system application is also possible. Data is automatically sent to P4 cloud-compute platform.
A pre-assembled computer, battery, solar-panel and stainless steel mounting bracket is mounted to an existing pole at the site or a stand-alone galvanized stand alone pole with drive-in base provided with the kit. A Pulsar dBi intelligent ultrasonic transducer (sensor) is hung in pendant mode (think plumb bob) within a access manhole riser by a sensor support bracket attached to the wall of the manhole riser using "TapCon" or similar fasteners. Direct bury cabling (within a 1-1/2" inner diameter conduit or not) can be used to run the sensor wire to the the computer system.
WHAT'S INCLUDED & OPTIONS
Included with Kit:
1.) Small form factor NEMA IP67 rated data acquisition computer with integrated cellular antenna
2.) Small form factor NEMA IP67 rated 12 VDC battery pack
3.) Voltaic 18V solar panel
4.) Stainless steel mounting bracket with stainless steel hose clamps for mounting (computer, battery, and solar panel pre-assembled on bracket)
5.) Pulsar dBi intelligent ultrasonic transducer (sensor).
6.) Sensor mounting bracket
Options:
1.) Stand-Alone galvanized steel mounting pole with drive-in base and corner bolt
2.) Direct-bury sensor extension wire (length dependent upon application)
3.) PVC conduit to protect wiring on stand-alone pole or existing pole.
INSTALLATION CONSIDERATIONS
Customers should assess the need for a stand-alone pole mount for the computer, battery and solar-panel. If no existing pole or other mounting location is present, the stand-alone pole option should be selected. Provisions should be made for a sensor wire conduit run from the access manhole riser to the computer system mounted to an existing or new stand-alone pole support.
P4 can provide installation services - CONTACT P4 for more information.
PRICING
P4-DEPTH Battery/Solar (starting at $4,425)
Pricing does not include installation or shipping- contact P4.
1-Yr P4 Cloud Compute Subscription - $225/yr/kit ($19/mth)
Multi-year cloud-compute subscriptions are available (contact P4)
Contact Continuous-Level Sensor - Battery/Solar Power
Contact Continuous-Level Sensor - Battery/Solar Power
Contact Continuous-Level Sensor - Battery/Solar Power
APPLICATON
LIQUA-Level is a popular choice for water-level monitoring. LIQUA-Level can be used for measuring water level for surface detention/infiltration systems, below-ground detention/infiltration systems, sumps, groundwater wells, infiltration dry wells, and stormwater infrastructure that incorporates observation wells. Data is automatically sent to P4 cloud-compute platform.
A pre-assembled computer, battery, solar-panel and stainless steel mounting bracket is mounted to an existing pole at the site or a stand-alone galvanized stand-alone pole with drive-in base provided with the kit. A Rochester Gauges (FPI) 316 SS intrinsically-safe continuous water-level sensor offering measuring ranges from 6 in. to 10 ft is used. The sensor length required will affect pricing.
WHAT'S INCLUDED & OPTIONS
Included with Kit:
1.) Small form factor NEMA IP67 rated data acquisition computer with integrated cellular antenna
2.) Small form factor NEMA IP67 rated 12 VDC battery pack
3.) Voltaic 18V solar panel
4.) Stainless steel mounting bracket with stainless steel hose clamps for mounting (computer, battery, and solar panel pre-assembled on bracket)
Options:
1.) Rochester Gauges (FPI) 316 SS intrinsically-safe continuous water level sensor with length defined according to application.
2.) Stand-Alone galvanized steel mounting pole with drive-in base and corner bolt
3.) Direct-bury sensor extension wire (length dependent upon application)
4.) PVC conduit to protect wiring on stand-alone pole or existing pole.
5.) Sensor mounting system selected based upon application
INSTALLATION CONSIDERATIONS
Customers should assess the need for a stand-alone pole mount for the computer, battery and solar-panel. If no existing pole or other mounting location is present, the stand-alone pole option should be selected. Provisions should be made for a sensor wire conduit run from the access manhole riser to the computer system mounted to an existing or new stand-alone pole support.
P4 can provide installation services - CONTACT P4 for more information.
PRICING
P4 LIQUA-Level (starting at $2,590)
Pricing does not include installation or shipping - contact P4.
1-Yr P4 Cloud Compute Subscription - $225/yr/kit ($19/mth)
Multi-year cloud-compute subscriptions are available (contact P4)
Pressure Based Sensor - Battery/Solar Power
Contact Continuous-Level Sensor - Battery/Solar Power
Contact Continuous-Level Sensor - Battery/Solar Power
APPLICATION
LIQUA-Level EPC is ideal for large surface infiltration basins and utilizes an innovative application of a Geokon pressure cell. LIQUA-Level EPC addresses the challenges associated with monitoring water level where sensor support is infeasible and large water level measuring ranges is required.
A pre-assembled computer, battery, solar-panel and stainless steel mounting bracket is mounted to an existing pole at the site or a stand-alone galvanized stand-alone pole with drive-in base provided with the kit. A Geokon Fat Back pressure transducer (sensor) is buried at the bottom of the infiltration basin.
WHAT'S INCLUDED & OPTIONS
Included with Kit:
1.) Small form factor NEMA IP67 rated data acquisition computer with integrated cellular antenna
2.) Small form factor NEMA IP67 rated 12 VDC battery pack
3.) Voltaic 18V solar panel
4.) Stainless steel bracket with stainless steel hose clamps for mounting (computer, battery, and solar panel pre-assembled on bracket)
5.) Geokon Fat Back pressure transducer (sensor) with 15 ft of direct bury wiring.
Options:
1.) Stand-Alone galvanized steel mounting pole with drive-in base and corner bolt
2.) Direct-bury sensor extension wire (length dependent upon application)
3.) PVC conduit to protect wiring on stand-alone pole.
INSTALLATION CONSIDERATIONS
Customers should assess the need for a stand-alone pole mount for the computer, battery and solar-panel. If no existing pole or other mounting location is present, the stand-alone pole option should be selected. Provisions should be made for a sensor wire conduit run from the sensor to the computer system mounted to an existing or new stand-alone pole support. Customers should also consider the need to bury the pressure sensor at a depth below the bottom of the basin. Frost depth should be considered.
P4 can provide installation services - CONTACT P4 for more information.
PRICING
P4 LIQUA-Level (starting at $3,900)
Pricing does not include installation or shipping - contact P4.
1-Yr P4 Cloud Compute Subscription - $225/yr/kit ($19/mth)
Multi-year cloud-compute subscriptions are available (contact P4)
